SPECIFICATIONS
Scanning Speed
90 pages per minute (ppm) in simplex (one-sided) mode at 300 dpi.
180 images per minute (ipm) in duplex (two-sided) mode at 300 dpi.
Resolution
Optical: Up to 600 x 600 dpi.
Enhanced: Up to 1200 x 1200 dpi.
Color Depth
48-bit internal color depth (for more accurate color reproduction).
24-bit color output.
Interface
USB 3.2 Gen 1 (USB 3.0) for fast data transfer.
Optional Network Interface: Available with the network model (fi-8190N).
Paper Handling
Automatic Document Feeder (ADF)
Capacity: 100 pages (80 g/m² or 20 lb paper).
Supports various paper sizes: A4, A5, B5, legal, and custom sizes.
Supports paper weights from 27 lb to 110 lb (80 g/m² to 413 g/m²).
Handles documents such as receipts, invoices, business cards, and photos.
Duplex Scanning
Yes, the scanner can automatically scan both sides of a document in a single pass.
Flatbed Scanning
The scanner includes a flatbed for scanning delicate documents, such as books, passports, and fragile items.
Feeding Technology
Reverse Roller Mechanism: Ensures paper is separated reliably and reduces jams.
Ultrasonic Double Feed Detection: Prevents double feeding by detecting multiple sheets of paper.
Paper Protection: Features such as Paper Protection Mode that help prevent document damage during scanning.
Scan Size
Supports documents up to A4 size (8.5" x 11.7").
Can scan longer documents up to 118" (3000 mm) in simplex mode.
Image Processing Features:
Image Enhancement
Automatic features like auto-crop, auto-deskew, and blank page removal to improve scanning accuracy and efficiency.
Supports multi-image output, which allows the creation of multiple files from a single scan.
Advanced Image Quality
Color Detection: Automatically detects color, grayscale, or monochrome content and adjusts accordingly.
Auto-Crop and Deskew: Automatically corrects skewed images and crops the document to the correct size.
Long-Page Scanning:
Can scan documents up to 118" (3000 mm) in simplex mode and 236" (6000 mm) at lower resolution settings.
Software Bundled
ScanSnap: User-friendly software for easy scanning workflows.
PaperStream IP: TWAIN and ISIS drivers for easy integration with document management systems.
PaperStream Capture: Advanced capture software for high-quality document scanning.
Fujitsu Scanner Central Admin Tool: For centralized management of scanners in a networked environment.
ABBYY FineReader (OCR software): For converting scanned documents into editable formats (available with certain packages).
Performance and Reliability
Duty Cycle
Recommended daily duty cycle: Up to 8,000 pages per day.
Maximum daily duty cycle: 12,000 pages.
Power Consumption
Power Supply: 100-240V AC, 50/60 Hz.
Power Consumption
Active: Approx. 45W.
Standby: Approx. 1.5W.
Physical Specifications
Dimensions (W x D x H)
305 mm x 210 mm x 168 mm (12.01" x 8.27" x 6.61").
Weight:
Approximately 5.2 kg (11.46 lbs).
Additional Features:
LCD Display
A simple display to monitor scanning status and settings.
Energy-Efficient
ENERGY STAR certified, ensuring low energy consumption.
RoHS compliant (Restriction of Hazardous Substances).
Operating Systems
Windows: Windows 10, 8.1, 7 (32/64-bit), Windows Server 2019/2016/2012.
Mac OS: Not officially supported (third-party software may be required for Mac compatibility).
Optional Accessories
Network Version: Fujitsu fi-8190N model with network scanning capability.
Summary
The Fujitsu fi-8190 is a high-performance A4 duplex document scanner capable of scanning at speeds of up to 90ppm/180ipm. With a 100-page ADF and support for various paper sizes and weights, it's ideal for businesses with high-volume scanning needs. It includes advanced image processing features, including automatic deskew, auto-crop, and ultrasonic double-feed detection for efficient, reliable scanning. Bundled with powerful software like PaperStream IP and ABBYY FineReader, this scanner is perfect for streamlining document workflows and improving productivity. The fi-8190 is built for businesses requiring a robust, efficient, and high-quality scanning solution
