FUJITSU FI-7300NX DOC SCANNER A4 DUPLEX 60PPM USB3.1
*Stock Are Subject to Availability
SKU
FAFI-7300NX
Product Reference :
|
$2,307.00
The fi-7300NX boasts a speed of 60 ppm/120 ipm (200/300 dpi) for scanning A4 portraits, loads up to 80 sheets at a time, and ensures utmost efficiency as the first standalone* scanner in the world to support 5 GHz Wi-Fi.
- Scan from the scanner with touch screen operation
- Various authentication methods for improved efficiency and security
- Scan from your smart device to any business platform
- 3 types of SDKs to suit any environment
- Paper streem NX Manager and Scanner Central Admin for centralized management
- Paper Protection function protects scans from jamming by detecting anomalies in document length and sound
- Manual Feed Mode for scanning folded or bound documents
| Product Name | fi-7300NX | |
|---|---|---|
| Scanner Type | ADF (Automatic Document Feeder)/Manual Feed, Duplex | |
|
Scanning Speed A4 Portrait |
Simplex: 60 ppm (200/300 dpi) Duplex: 120 ipm (200/300 dpi) |
|
| Image Sensor Type | Color CCD x 2 (front x 1, back x 1) | |
| Light Source | White LED Array x 2 (front x 1, back x 1) | |
| Optical Resolution | 600 dpi | |
| Output Resolution Color/Grayscale/Monochrome |
50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi driver | |
| Output Format | Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit | |
| Background Colors | White / Black (selectable) | |
| Document Size | Maximum | 216 x 355.6 mm (8.5 x 14 in.) |
| Minimum | 50.8 x 54 mm (2 x 2.1 in.) | |
| Long Page Scanning | 5,588 mm (220 in.) | |
| Paper Weight (Thickness) | Paper | 27 to 413 g/m² (7.2 to 110 lb) (9) |
| Plastic Card | 1.4 mm (0.055 in.) or less (10) | |
| ADF Capacity | 80 sheets (A4 80 g/m² or Letter 20 lb) | |
| Expected Daily Volume | 9,000 sheets | |
| Multifeed Detection | Overlap detection (Ultrasonic sensor), Length detection | |
| Paper Protection | Lag detection, Sound detection (iSOP) (14) | |
| Display | 4.3 in. TFT color touch screen | |
| Authentication | Keyboard (on touch screen), NFC | |
| Interface | USB | USB 3.1 Gen1 / USB 3.0 / USB 2.0 / USB 1.1 |
| Ethernet | 10BASE-T, 100BASE-TX, 1000BASE-T | |
| Wi-Fi | IEEE802.11 a/b/g/n/ac Frequency band: 2.4 GHz / 5 GHz (15) |
|
| Wi-Fi Interface | Rated Power (EIRP) (North America) |
2.4 GHz: 11b: +23.5dBm, 11g: +22.0dBm, 11n/ac: +22.0dBm (20/40MHz) 5 GHz (15): 11a: +15.5dBm, 11n/ac: +16.5dBm (20MHz) |
| Rated Power (EIRP) (Others) |
2.4 GHz: 11b: +19.0dBm, 11g: +20.5dBm, 11n/ac: +20.5dBm (20/40MHz) 5 GHz (15): 11a: +15.5dBm, 11n/ac: +16.5dBm (20MHz) |
|
| Network Protocols | IPv4 (16), TCP, UDP, ICMP, DHCP, HTTP/HTTPS, DNS | |
| Power Requirements | AC 100 to 240 V ±10 % | |
| Power Consumption | Operating | 42 W or less |
| Power Saving | 2.4 W or less | |
| Power Off | 0.35 W or less | |
| Operating Environment | Temperature | 5 to 35 °C (41 to 95 °F) |
| Relative Humidity | 20 to 80% (Non-condensing) | |
| Environmental Compliance | ENERGY STAR®, RoHS | |
| Dimensions (W x D x H) | 300 x 202 x 170 mm (11.8 x 7.9 x 6.6 in.) | |
| Weight | 4.9 kg (10.8 lb) or less | |
| Supported Operating System | Windows® 10 (19), Windows® 8.1, Windows® 7, Windows Server® 2019, Windows Server® 2016, Windows Server® 2012 R2, Windows Server® 2012, Windows Server® 2008 R2, Windows Server® 2008 (20) Find more information for PaperStream NX Manager |
|
| Included Software / Drivers | PaperStream IP Driver (TWAIN/TWAIN x64/ISIS), WIA Driver (21), PaperStream Capture, ScanSnap Manager for fi Series (22), Software Operation Panel, Network Setup Tool, ABBYY FineReader for ScanSnap™ (22), Scanner Central Admin | |
| Image Processing Functions | Error diffusion, Dither | |
| Included Items | Chuter unit, AC cable, AC adapter, USB cable, Setup DVD-ROM | |
