General Specifications
Scanner Type: Sheetfed & Flatbed A4 Colour Image Scanner
Sensor Type: Contact Image Sensor (CIS)
Light Source: 3 Colour RGB LED (provides high-quality, accurate colour scanning)
Resolution
Flatbed: 1,200 x 1,200 dpi (for high-definition image scans)
ADF (Automatic Document Feeder): 600 x 600 dpi (suitable for document scanning with fast speed)
Maximum Effective Scan Area
Flatbed: 216 x 297 mm (8.5 x 11.7 inches - A4/Letter size)
ADF: 216 x 356 mm (8.5 x 14.0 inches - Legal size)
Grayscale: 8-bit external, 8-bit internal
Colour: 24-bit external, 30-bit internal
Interface
USB 3.0 (provides fast data transfer)
Optional Network Interface Unit (RJ-45, 10BaseT/100BaseTX)
Scanning Performance
Daily Duty Cycle: 1,500 sheets (designed for high-volume scanning)
Buttons:
Power, Scan, Stop (easy-to-use physical buttons)
Scanning Speed
Monochrome: A4 at 300 dpi (PDF), 25 ppm (pages per minute)
Colour: A4 at 300 dpi (PDF), 10 ipm (images per minute)
ADF (Automatic Document Feeder)
ADF Type: Sheet-through, Simplex scanning
Paper Supply: Face-up load, Paper-out face-down eject
Document Sizes Supported: A4, Letter, Legal, B5, A5, A6
Max. size: 216 x 356 mm
Min. size: 105 x 148.5 mm
Paper Setting Capacity: 50 pages (75 g/m²)
Paper Weight: 50 - 120 g/m² (supports a range of paper weights)
Scanning Functions
Easy Document Scanning
Double-sided scanning (for both sides of a document)
Searchable PDF (Windows only)
Multi PDF (scan to multiple PDFs)
Encrypted PDF
Compression PDF
Scan to File Feature
Auto Skew Correction, Multi Marquee
Document Image Adjustment
Text enhancement, Colour enhancement
Dropout colour, Unsharp mask
De-Screening with Document Type Optimizer
Tone Curve Adjustment with Histogram
Supported Platforms
Windows: Windows 10, 8/8.1, 7
Mac OS: macOS 10.6.8 - 10.11.x
Environmental Conditions
Operating Temperature: 10°C to 35°C
Storage Temperature: -25°C to 60°C
Operating Humidity: 20% to 80% (without condensation)
Storage Humidity: 20% to 85% (without condensation)
Electrical Specifications
Rated Voltage: AC 100-240V, 50-60Hz
Power Consumption:
Approx. 11W (Operating)
Approx. 0.8W (Sleep Mode)
Approx. 5.8W (Ready Mode)
Approx. 1.5W (Power Off)
General Information
Bundled Software
Epson Scan
Online User Guide
ISIS Driver for Windows
Warranty: 12 months return-to-base warranty
Physical Dimensions
Dimensions
450 mm (W) x 318 mm (D) x 121 mm (H)
Weight: Approx. 6 kg (compact yet sturdy design)
